Default How to make your own low profile car ramps


Super easy to do, I made mine about 4 years ago and they still look like new. They could support a house they are so strong and are a heck of a lot cheaper than buying "race ramps".

Just an option for you to have. If you do not like it, then do not build it.

Click the image to open in full size.

http://www.mustangworld.com/ourpics/...amps/index.htm

For slammed stangs and the DIY'er

If your stang is lowered more than 2 inches, or you just find it a PITA to lift the front of your car then you might need to make yourself some MW ramps :-)
(DIY means "Do it yourself" of course)


Click the image to open in full size.



Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote
  #2 (permalink)
Old 02-26-2009, 09:25 AM
Senior Member

Join Date: Feb 2008
Posts: 3,793
Default Re: How to make your own low profile car ramps


Our stock 2000 on the ramps.
One of the key things in getting motivated to do your own oil changes or modding your stang is being able to easily, quickly and safely lift your stang. If it's going to take 15 minutes for you to jack up the front end of your stang one side at a time with a jack and jack stands, chances are you won't be too motivated to install that supercharger you had sitting in your garage for the past 5 months :-)
The next problem is if your stang is already slammed (lowered), then you have a real challenge lifting the front end with probably only 1" - 2" of clearance.

Other Ramps

We reviewed Rhino Ramps a few years back which is probably the best store bought alternative (for the price), but the things we don't like about them and other ramps were that on a lowered stang, you still scrape the black lower portion, and most ramps are a single incline ramp, which means any mishap and that stang is rolling down to the ground in one shot. Also most store ramps are very light weight, which means they can slide on a smooth floor when trying to drive up onto them.

We wanted ramps that addressed all these problems that were the same price or less to make than some store bought ramps.
Let's Build

Click the image to open in full size.

MW Ramps sketch. Cost to make: Around $30 in wood

Materials: 2" x 10" x 10 foot (two), 2" x 10" x 8 foot (two) and a 2" x 3" x 10" piece.
This isn't New Yankee Workshop, so just a quick overview.. :-)



Click the image to open in full size.Click the image to open in full size.


Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote
  #3 (permalink)
Old 02-26-2009, 09:25 AM
Senior Member

Join Date: Feb 2008
Posts: 3,793
Default Re: How to make your own low profile car ramps


Click the image to open in full size.Click the image to open in full size.

Go to your local lumber store and buy the pieces of wood mentioned above. You can get them in different lengths. Try to find dry wood that's not warped. You might buy 20 foot long pieces and cut them according to our sketch. We made at least an 18" stretch between steps to accommodate the stang's long nose and to avoid scraping ground effects on most slammed stangs. Building is easy, simply nail the pieces together as shown, taking care to pre-drill a slightly smaller hole for the nails, so you don't run the risk of splitting the wood. Bend the nails over at the bottom of each ramp if they stick out.. You may also glue the parts together to boot.

Click the image to open in full size.



Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote
  #4 (permalink)
Old 02-26-2009, 09:26 AM
Senior Member

Join Date: Feb 2008
Posts: 3,793
Default Re: How to make your own low profile car ramps


Finished Ramps.


10" wide is good for wide tires.. Got wider ? You can get 2 x 11's if need be.
Click the image to open in full size.Click the image to open in full size.
This is with the stock springs, but you can see plenty of room.





Drive on up

ON A FLAT LEVEL SURFACE, just drive up the ramps. The stopper piece will prevent you from driving off and each step is easily rolled onto. Then lay a wheel stop "behind" the front wheels and you are ready to work. Each ramp weighs enough so they should not slide when driven onto slowly.

If you are on an uneven surface, you might need to shim the ramps to get them level and to ensure they lay flat. You can also place jackstands as a backup if you wish.
What kind of lift
It raises the stang about 6" (a little higher than rhino ramps as an example) and it's high enough to do most under chassis engine / h-pipe work. Need higher ? You can add an extra step (before the rear tire hits the ramps even).


Click the image to open in full size.Click the image to open in full size.


Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote
  #5 (permalink)
Old 02-26-2009, 09:26 AM
Senior Member

Join Date: Feb 2008
Posts: 3,793
Default Re: How to make your own low profile car ramps


Click the image to open in full size.Click the image to open in full size.
Click the image to open in full size.Click the image to open in full size.
Access is from the front. You can swap an H-pipe and easily access the lower engine. For more space or for oil changes you can lift the rear to level out the stang. You can also now lift one side of the stang at a time up front (a tiny amount) easily with a floor jack for changing the front tires for example.
Is wood strong enough ?
Let just say laid flat the wood can lift your entire house (many tons) with no worry. The only worry we have (way back in our minds) is wood splitting, but if you pre-drilled your nails and / or glued your wood together, you should have absolutely no problems.

The "stepped" nature of the ramps
The stepped nature of the ramps also means that if for some reason you forgot to put a wheel stop behind your tires and you start jacking up the rear, your stang may only roll down one step, NOT roll down the entire ramp. Most other store ramps are single incline or 2 piece ramps, not stepped like these home made units :-)

Only 1.5" clearance needed
For most lowered stangs (or other cars) lifting is no problem, because we only need 1.5" in front of the tires. We have 18" of space before each step which covers the lower edges on many body kits. If you need more room, you can extend the step interval to 20+ inches. You can see there is plenty of room left before the ramps hit our rear tires.


Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote
  #6 (permalink)
Old 02-26-2009, 09:27 AM
Senior Member

Join Date: Feb 2008
Posts: 3,793
Default Re: How to make your own low profile car ramps


Click the image to open in full size.

The bottom line...

If you could not find yourself the "right" set of ramps in stores or are tired of jacking up the front end one side at a time or bending your center crossmember with your jack, or can't get a jack under your front end... you can see making a set of home ramps is fairly easy and you can make them to your very own specs.

The cost of the wood can vary, so these are not really "poor mans" ramps in some cases home made may cost a few dollars more, but since it's to your own specs, we like that :-)
We gave our ramps a coat of paint after these shots were taken.
Extra notes:
These ramps will weigh 30 - 40 pounds each depending on how dry the wood is, so they are mainly for home use (not really portable). We still have all our other ramps (Rhino, metal, 2 stage, etc) and use them when we can for different jobs.


Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote
  #7 (permalink)
Old 02-26-2009, 09:50 AM
Senior Member

Join Date: Apr 2006
Location: Canada
Posts: 13,953
Default Re: How to make your own low profile car ramps


Thats just whats needed, cheap and cheerful and most importantly SAFE.
Reply With Quote
  #8 (permalink)
Old 02-26-2009, 09:57 AM

Join Date: Apr 2008
Location: Fort Belvoir, Virginia
Posts: 27
Default Re: How to make your own low profile car ramps


Thanks Mrphotoman for the instructions and the pics. Good info
________
TeenageDreams

Last edited by boricua1; 08-20-2011 at 12:50 PM.
Reply With Quote
  #9 (permalink)
Old 02-26-2009, 10:34 AM
Senior Member

Join Date: Feb 2008
Posts: 3,793
Default Re: How to make your own low profile car ramps


They are nice and sturdy and wide, I love mine. I threw my 2 sets of plastic ramps in the building and have not used them for years now.

Saves money and works great.


Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote
  #10 (permalink)
Old 02-26-2009, 10:52 AM
GDC-SRT's Avatar
Senior Member

Join Date: Dec 2007
Location: Mn
Posts: 2,309
Default Re: How to make your own low profile car ramps


WOW!

I bet you could even angle cut each step front, @ say 30 degree,and make driving on easier!

Good post Photodude!
Reply With Quote
  #11 (permalink)
Old 02-26-2009, 12:21 PM
AlG AlG is offline
Forum Regular

Join Date: Jul 2007
Location: Merrick, NY
Age: 60
Posts: 548
Send a message via AIM to AlG
Default Re: How to make your own low profile car ramps


Just out of curiosity..how much do each one of those things weigh. Seems like I would think about 20 pounds each and being over 6 feet long they look like they're not so easy to store.
Reply With Quote
  #12 (permalink)
Old 02-26-2009, 01:10 PM
Senior Member

Join Date: Feb 2008
Posts: 3,793
Default Re: How to make your own low profile car ramps


Quote:
Originally Posted by GDC-SRT
WOW!

I bet you could even angle cut each step front, @ say 30 degree,and make driving on easier!

Good post Photodude!
I actually like the "steps" on them, I know how many they are and it lets me know how close to the top I am because I can count as I drive up them lol.


Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote
  #13 (permalink)
Old 02-26-2009, 01:59 PM
James1549's Avatar
Senior Member

Join Date: May 2008
Location: Cincinnati ( Delhi )
Posts: 8,992
Default Re: How to make your own low profile car ramps


Looks like the set I made about 20 years ago. Mine are about 5' long. You can turn one upside down on top of the other for storage. Fits like a glove to each other. James


Reply With Quote
  #14 (permalink)
Old 02-26-2009, 04:28 PM
Serendip's Avatar
Join Date: Jan 2009
Location: Richmond KY
Posts: 64
Default Re: How to make your own low profile car ramps


Just to stir things up, check out this link: http://www.classic1800.com/ramp-pit-plans/

I don't know if I'd want to try it myself, but it is an interesting idea.


Perfection in design is achieved not when there is nothing more to add, but when there is nothing left to take away.
Antoine de Saint-Exupery


Two things in my life that qualify:


Reply With Quote
  #15 (permalink)
Old 02-26-2009, 05:06 PM
Forum Regular

Join Date: Sep 2008
Posts: 334
Default Re: How to make your own low profile car ramps


I was going to build some of them for my cobra, but some drunk uninsured foreigner took care of that problem for me. God I miss that car.


04 black crossfire
lowbeams, and fog hid's 6000k
forte aftermarket wheels
pioneer 6000 headunit
JLHD 750/1 amp
12W6 in a ported box
SVR 34/78 yellow top battery

07 blue zx14, high and lowbeam 6000k hid's

97 pg cobra, with full road race suspension, 18x9's, and 18'10's, gears, shifter. Totalled 9/13/08, by a DRUNK DRIVER!!!
Reply With Quote
  #16 (permalink)
Old 02-26-2009, 05:08 PM
Senior Member

Join Date: Apr 2006
Location: Canada
Posts: 13,953
Default Re: How to make your own low profile car ramps


Quote:
Originally Posted by Serendip
Just to stir things up, check out this link: http://www.classic1800.com/ramp-pit-plans/

I don't know if I'd want to try it myself, but it is an interesting idea.

Perfection in design is achieved not when there is nothing left to add, but when there is nothing left to take away.
Antoine de Saint-Exupery
Good idea, ....I think.
I like your quote in the signature, as a tool designer I try to live by that rule, its great for keeping costs down as well.
Reply With Quote
  #17 (permalink)
Old 02-26-2009, 06:14 PM
Franc Rauscher's Avatar
Senior Member

Join Date: Mar 2008
Location: St Louis MO
Posts: 12,677
Default Re: How to make your own low profile car ramps


Very clever Mrphotoman.

I'm going to make a set for loading my trailer. I hate my curent steel ramps. Never feel safe on them.

thanks.


roadster with a stick
Reply With Quote
  #18 (permalink)
Old 12-23-2009, 06:20 PM
HowardJ's Avatar
Forum Regular

Join Date: Jun 2009
Location: Indiana
Age: 22
Posts: 421
Send a message via AIM to HowardJ
Default Re: How to make your own low profile car ramps


I bought two 2x10x8 boards.
Plan on doing: 4', 2.5', and 1.5' steps.
Reply With Quote
  #19 (permalink)
Old 12-24-2009, 12:36 PM
Bazzer's Avatar

Join Date: Oct 2009
Location: United Kingdom
Posts: 273
Default Re: How to make your own low profile car ramps


I find these do the job just perfect.

Click the image to open in full size.


2005 Grey Crossfire Coupe 6 speed manual.

Reply With Quote
  #20 (permalink)
Old 06-06-2010, 08:31 PM
Senior Member

Join Date: Feb 2008
Posts: 3,793
Default Re: How to make your own low profile car ramps


another DIY ramp project


Build Ramps for your C2 or C3 Corvette
(An excellent alternative to expensive car hoists and car lifts)
Have you ever wished there was an easy way to get your Corvette up in the air so you could comfortably work under it? Here is a safe and inexpensive way to construct a set of portable ramps. Instructions:

The ramps are indeed easy to build. Both sections are built identical. The ramps are 10'9" in length. You can construct them from 2"x10" or 2"x12". In this set I used 2"x10" and then nailed a couple of lengths of 1"x6" on each side on the bottom to give some extra lateral support. (If you use 2"x12" you will have more room to place a hydraulic jack under the frame in case you need to place jack stands under the frame). The top and bottom are 2"x10" or 12" with 2"X10" or 12" uprights on 16" centers. You will need 2 sheets of 1/2" plywood or wafer board for the sides. Rip each sheet of plywood into 3 strips 16" wide. It will take one sheet per ramp. Use 2 1/2" spiral nails or 2" drywall screws to attach the side pieces to your framework. Use 3 1/2" spiral on the actual framework. On the ends where the car comes up, attach another piece of 2" x 10" to support the planks for driving the car up on. These 2 planks only need to be about 7' long with a couple supports under them. I used a couple of rubber ramps to support the planks. With that short a length my side pipes still clear fine. You can mount a couple of permanent lights and a 110v receptacle on the inner sides of the supports if you wish. That makes it much easier than fighting power cords. If you have a good level floor they will be very stable and will support a bulldozer. I can almost sit on the floor under the car but not quite. I mark the floor with a felt marker so that each time it only takes me about 5 minutes to place them and drive the car up on them.

Here are some pictures of what your finished product will resemble.
Click the image to open in full size.
Car parked on ramps awaiting the blocks behind the rear wheels.
Click the image to open in full size.
Ramps 2" wider than these will give you more room to place jack stands.
Click the image to open in full size.
Note the blocks spiked up front for wheel stops.
Click the image to open in full size.
You might want to place blocks behind the rear wheels if the car is going to be in neutral.
Click the image to open in full size.
This gives you some idea of the height you have for working.
Click the image to open in full size.
An old sleeping bag makes a nice pad for lying on when under the car.
Click the image to open in full size.
You can see the rubber pads that I use for extra support for driving up and down.
Click the image to open in full size.
I sometimes attach a board to keep the ramps aligned when I drive up on them.
Click the image to open in full size.
You can store the ramps along the wall of your shop when not in use.


Code3 Pulley_Inmotion Custom Tune_Needswings Intake_AIS Meth Injection

1/4: 11.86@116.76 1/8: 7.64@92.19 60': 1.70
Reply With Quote

Old 06-06-2010, 08:31 PM
Advertisement
Default Re: How to make your own low profile car ramps





Reply


Currently Active Users Viewing This Thread: 1 (0 members and 1 guests)

Thread Tools

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are On
Pingbacks are On
Refbacks are On



All times are GMT -4. The time now is 01:57 AM.
