Careful. THe fuse positions and assignments vary based on year and trim level.
We learned this at a North Georgia Tech Day at Tricia's place in Oakwood when I was doing the "ALways hot cigarette lighter and glove box light mod" for a few attendees.
Example:
The 05 Base Coupe's spoiler fuse was on ignition and in a different location than the 05 Limited Roadster and 07 SE (which were both on battery). (The Spoiler fuse is where I get battery feed for my mod, in the base car, I had to go elsewhere, I used the battery-fed fuse for the am/fm radio.)
I would bet money there are other changes they made as well. This is something to keep in mind when using the forum's 05 SRT Roadster service manual and the forum's 04 Coupe service manual - neither applies 100% to all cars; cause that would be too easy.
Careful. THe fuse positions and assignments vary based on year and trim level.
We learned this at a North Georgia Tech Day at Tricia's place in Oakwood when I was doing the "ALways hot cigarette lighter and glove box light mod" for a few attendees.
Example:
The 05 Base Coupe's spoiler fuse was on ignition and in a different location than the 05 Limited Roadster and 07 SE (which were both on battery). (The Spoiler fuse is where I get battery feed for my mod, in the base car, I had to go elsewhere, I used the battery-fed fuse for the am/fm radio.)
I would bet money there are other changes they made as well. This is something to keep in mind when using the forum's 05 SRT Roadster service manual and the forum's 04 Coupe service manual - neither applies 100% to all cars; cause that would be too easy.
I have a scanned fuse sheet from a 2005 SRT6 this is a good place to put it.
Last edited by onehundred80; Sep 6, 2019 at 11:31 PM.
Engine Compartment fuse list
